Mantra MBAS20 4G Aadhaar Enabled Biometric Attendance System (L1 Certified)
Free Shipping • 1 Year Warranty • L1 Certified Device
Product Specification
| Brand | Mantra |
|---|
| Model | MBAS20 4G |
|---|
| Fingerprint Sensor | Scratch-Free Optical FAP10 L1 Sensor (STQC L1 & FBI PIV Certified) |
|---|
| Image Specs | 276 × 336 pixels, 500 DPI (±2%), 256 Gray Levels |
|---|
| Display | 7" TFT LCD, 1024×600 Resolution |
|---|
| Touchscreen | Multi-point capacitive, 6H toughened scratch-resistant glass |
|---|
| Processor | ARM Cortex A53 Quad-Core @ 1.5GHz |
|---|
| Memory | 2GB RAM + 16GB Flash |
|---|
| Front Camera | 2 MP Fixed Focus |
|---|
| Rear Camera | 5 MP Auto Focus + Flash LED |
|---|
| Card Reader | 13.56 MHz Contactless (Optional) |
|---|
| Battery | 4000 mAh Li-ion Rechargeable |
|---|
| Connectivity | 4G, 3G, 2G, Wi-Fi 2.4/5GHz, Ethernet, Bluetooth & GPS |
|---|
| OS | Android 10 |
|---|
| Ports | Micro USB, SIM Slot, DC Input, RS-485, USB 2.0 (optional) |
|---|
| Dimensions | 221 × 181 × 48 mm |
|---|
| Weight | Approx. 0.8 kg |
|---|
| Certifications | CE, RoHS, BIS, IP54 |
|---|
Technical Specification
| 4G/3G/2G Bands | B1/B3/B5/B7/B8/B38/B40/B41 |
|---|
| Wi-Fi | IEEE 802.11 a/b/g/n (2.4 & 5 GHz) |
|---|
| Ethernet | 10/100 Mbps |
|---|
| GPS | 16 Channel NMEA, AGPS Supported |
|---|
| Smart Card | ISO14443 A/B, MIFARE Classic, DESFire EV1/EV2, NTAG |
|---|
| GPIO | 1 Input / 1 Output |
|---|
| Relay | 5V/3A Relay Output |
|---|
| Temperature | 0°C to 50°C (Operating) |
|---|
| Humidity | 10%–90% RH (Non-Condensing) |
|---|
Product Description
The Mantra MBAS20 4G Aadhaar Enabled Biometric Attendance System is a
high-performance AEBAS device designed for secure Aadhaar-based authentication,
eKYC, attendance monitoring, and access control. It features an
STQC L1 & FBI PIV certified FAP10 fingerprint sensor,
7-inch TFT display, quad-core processor, and a rugged design suitable for
government, banking, and enterprise-level biometric applications.
With built-in 4G, Wi-Fi, GPS, Bluetooth, and Ethernet, the MBAS20 ensures
seamless connectivity in field and office environments. Its powerful 4000 mAh
battery with auto sleep/wake ensures long operational hours and energy efficiency.
Key Features
- STQC L1 & FBI PIV Certified FAP10 Fingerprint Sensor
- 7-inch TFT display with scratch-resistant 6H toughened glass
- Quad-core ARM Cortex A53 1.5GHz processor with Android 10
- Integrated 4G, Wi-Fi (2.4/5GHz), Bluetooth, Ethernet, and GPS
- 4000 mAh rechargeable battery with auto sleep/wakeup
- 2MP front and 5MP rear camera with LED flash
- Optional contactless smart card reader (13.56 MHz)
- Supports AEBAS, eKYC, Access Control & Time Attendance
- IP54 rated rugged build for field use
Applications
- Aadhaar Enabled Biometric Attendance System (AEBAS)
- Government employee attendance monitoring
- Banking & eKYC verification
- Insurance & telecom identity verification
- Access control & manpower management
- School, corporate, and industrial attendance
