The GlobalSat BU-353N is a USB GPS receiver that is designed for high-performance accuracy and reliability in compact
form. With a SiRF Star IV chipset, it is a best-in-class receiver for some of the most hostile environments, such as
urban canyons or dense foliage, performing very precise positioning where traditional GPS devices fumble. One of the
main features of the BU-353N is that it uses SiRF CGEE technology, allowing the device to predict the position of
satellites for a period of up to 3 days ahead. This hugely improves its Time To First Fix, delivering a quick start
time of less than 15 seconds under most conditions, without network assistance. The MicroPower mode allows the
receiver to remain in a condition similar to hot start, continuously at very low power levels, while remaining ready
for instant use. The BU-353N is ideal for a wide range of applications, supporting 75-channel all-in-view satellite
tracking. This will provide robust performance across very demanding automotive navigation, personal positioning,
fleet management, mobile phone navigation, and marine navigation. It offers an easy way to connect through the USB
interface to Microsoft Windows 8, 10 and above, hence integration with several devices.
The design of the BU-353N is based on ease and durability. It has an internal patch antenna, which gives it
effortless mounting on any vehicle. In addition, a super adhesive magnetic base allows it to be fixed firmly
without its movement being put into concern. Its water resistant and non-slip bottom guarantees stable operations in
various weather conditions; It works both inside and outside the house. This model, BU -353N, is UIDAI -certified and
perfectly corresponds to the strict standards determined for the Aadhaar application. Therefore, it guarantees compliance and
reliability for support centers and related government services. The LED indicator clearly indicates status to the user through
its ON, OFF, and flashing modes regarding GPS fix status. The GlobalSat BU-353N driver is ready for download by any user who wants
to install the right drivers. The BU-353N5 GPS driver for Windows 10 ensures that it is compatible with the latest operating systems
so that all users can use them. On the price front, GlobalSat BU-353N continues to be competitive in the Indian market since it is
very affordable but with no compromising on its features or performance. The process of installation and setup is well explained in
the BU-353N manual, making the experience smooth for users. Whether you're navigating city streets or exploring remote landscapes,
the GlobalSat BU-353 N GPS receiver keeps on performing—powered by its reputation for quality and efficiency. Buy GlobalSat BU-353N
in India at the best price on the Rafs Plaza website or from our offline store.
Key Features & Benefits
✅ BU-3533 boasts a very high sensitivity chipset, with a tracking sensitivity of -165 dBm for stable functionality in harsh environments.
✅ The receiver has an extremely short first fix time (TTFF) at low signal level, enabling quicker satellite acquisition.
✅ NMEA 0183 compatible data protocol for easy connection with other applications.
✅ Built-in backup power reserves system data and ensures rapid satellite acquisition during operation.
✅ Integrated patch antenna enhances signal reception for improved accuracy.
✅ Designed with a super-cohesive magnetic base for easy and secure vehicle mounting.
✅ Water-resistant casing and non-slip bottom ensure stable operation in diverse weather conditions.
✅ USB connection port for easy connectivity to compatible devices.
🎯 Ideal Use Cases
Aadhaar Enrollment & Update Centers
Common Service Centers (CSCs)
Government Schemes (Digital India, PMGDISHA,Aadhaar Centre etc.)
Field Verification & eKYC Services
GIS Data Collection & Mapping Projects
Mobile POS & Biometric Verification Units
BU-3533N Specification
Electrical Characteristics (Receiver)
GPS Chipset
High performance chipset
Frequency
GPS, SBAS : L1,1575.42 MHz
C/A Code
1.023 MHz chip rate
Channels
75
Sensitivity
-165 dBm
Accuracy
Position Horizontal
< 2.5m 2D RMS SBAS Enable
Velocity
0.1m/sec 95% (SA off)
Time
1 micro-second synchronized to GPS time
WAAS
Enable for North America products (USGlobalSat, Inc)
Datum
Datum
WGS-84
Acquisition Rate
Hot Start
1 sec. (average, with ephemeris and almanac valid)
Software command setting (Default: 4800,n,8,1 for NMEA)
Dynamic Condition
Acceleration Limit
Less than 4g
Altitude Limit
18,000 meters (60,000 feet) max
Velocity Limit
515 meters/sec (1,000 knots) max
Jerk Limit
20 m/sec²
Environment
Operating Temperature
-40° ~ 85°C
Storage Temperature
-40° ~ 85°C
Humidity
Up to 95% non-condensing
Power
Voltage
5V ±5%
Current
42mA typical
Physical Characteristics
Dimension
2.08” diameter × 0.75” (53mm dia × 19.2mm)
USB Cable Length
60” (152 cm)
📩 RD Service or Driver Download Activation & Setup
The GlobalSat GStar BU-353N does not require any RD-service activation. It is plug-and-play with most Aadhaar based platforms. All driver and setup details are
provided and our support team is ready to help in the smooth installation and integration. To install the driver or to get the latest information in the GlobalSat BU-353N price,
you can call us at +91 9679868503 or +91 7001007044 or email us at sales@rafsedigital.com
