Mantra MFS500 Optical Fingerprint Scanner — FBI PIV Certified | IP54 | 500 DPI | Non-Aadhaar

Most fingerprint scanners make a trade-off: optical sensors that wear easily, or durable builds that compromise image quality. The Mantra MFS500 resolves that tension with a scratch-free optical sensor (MOPv2.0 OEM module) that captures sharp, consistent 500 DPI images even from dry, worn, or rough fingertips — and keeps doing so through years of daily use.

This is a non-Aadhaar fingerprint scanner — purpose-built for enterprise access control, PC logon security, time and attendance, banking KYC, and identity verification workflows where organisations need a reliable biometric device that integrates into their own systems, not a government-mandated stack.

Every scan is captured at 296 × 354 pixels across a 16.4 × 20.0 mm platen, with an auto finger-detection and auto-capture engine that applies NIST quality considerations before accepting an image — all completed in under 2 seconds. The result is a fingerprint record that consistently meets FBI PIV certification and Mobile-ID FAP10 standards, making it suitable for deployments where image quality is non-negotiable.

The MFS500 connects via USB 2.0 with true plug-and-play performance. The WHQL-certified driver ships with a unique device serial number for straightforward fleet management. It runs on Windows (x86 and x64), Linux, and Android — covering everything from fixed desktop workstations to Android-based biometric tablets without additional driver work. Biometric data is output in ISO 19794-2, ISO 19794-4, ANSI 378, WSQ3.1, and JPEG2000 formats, keeping integration options wide open across third-party AFIS, ABIS, and identity middleware platforms.

Built to IP54, the scanner handles the dust and moisture exposure that comes with real-world deployment at factory gates, hospital reception counters, bank branches, and outdoor kiosks. It draws power entirely from the USB bus at 5V, operates across 0–50°C, and weighs just 123g — light enough to deploy anywhere, robust enough to stay there.

Certifications: FBI PIV, Mobile-ID FAP10, CE, FCC Part 15B Class A, BIS IS 13252 (Part 1), EN/IEC 60950, RoHS, IP54, WHQL.

=== Product highlights ===

• Scratch-free optical sensor (MOPv2.0) captures clean 500 DPI images from dry, worn, or rough fingertips — consistent quality that standard optical sensors degrade over time

• FBI PIV certified and Mobile-ID FAP10 compliant — image quality meets federal identity verification standards for high-assurance enterprise and government deployments

• Non-Aadhaar design — built specifically for enterprise access control, PC security, banking KYC, time attendance, and identity systems that run on independent biometric platforms

• Auto finger detection with NIST-quality auto-capture completes the full fingerprint acquisition in under 2 seconds — no button press, no manual trigger needed

• IP54 rated body — dust and splash resistant for real-world deployment at factory gates, hospital reception desks, outdoor kiosks, and high-traffic commercial entry points

• USB 2.0 plug-and-play with WHQL-certified driver and unique serial number — installs in seconds on Windows x86/x64, Linux, and Android with no manual configuration

• Outputs in ISO 19794-2, ISO 19794-4, ANSI 378, WSQ3.1 and JPEG2000 — wide format compatibility for integration with third-party AFIS, ABIS, and identity middleware

• Native Android support (USB OTG) makes the MFS500 directly compatible with Android biometric tablets and mobile enrollment stations without adapters or workarounds

• Weighs just 123g at 85×51×54 mm — compact and lightweight enough for desktop, kiosk, or embedded OEM module deployment (module weight: 25g at 61×23×28.5 mm)

• Full compliance stack: CE, FCC Part 15B Class A, BIS IS 13252, EN/IEC 60950, RoHS — meets safety and EMC requirements for commercial deployment across India and internationally
